Home / JSI Cabinetry Designer Series - Norwich Recessed

JSI Cabinetry Designer Series - Norwich Recessed

One of the newest additions to our Designer Collection, Norwich Recessed, features premium light gray paint on a shaker style door with matching drawer fronts. Like all of our Designer Kitchens, Norwich comes standard with soft close doors and drawers.

  • Premium light gray paint on Maple Shaker Door
  • Standard with CARB II compliant all plywood box
  • 3/4" North American Maple Face Frame
  • Full-overlay design
  • Shaker-style door
  • Matching drawer front
  • 3/4˝ dovetail, full-extension, soft-close drawers
  • Soft-close hinges standard
  • Other accessories available

norwich recessed gray shaker door and drawer profile

Designer Series Construction Specs

1.  Face Frames

    3/4" thick x 1 1/2" wide solid North American maple
    2.  End Panel

      1/2 ̋-thick Plywood (Finished to match on exterior)
      3.  Top and Bottom (Walls)

        1/2 ̋-thick Plywood
        4.  Bottom (Bases)

          3/8 ̋-thick Plywood
          5.  Shelves

            Adjustable 3/4 ̋-thick Plywood, Edgebanded on front
            6.  Backs 1/2 ̋-thick Solid Plywood
            7.  Hang Rails (Walls)

              5/8 ̋-thick Solid Wood
              8.  Toe Kick

                1/2 ̋-thick Plywood, Unfinished, Recessed
                9.  Drawer Box

                  Dovetail with 3/4 ̋-thick solid wood sides and 3/8 ̋-thick bottom
                  10.  Glides

                    Full-extension, soft close, undermount drawer glides
                    11.  Hinges

                      6-way-Adjustable, Concealed, with Soft Close Integrated Hinge
                      • Interiors

                      Finished in Natural Maple
                      • Soft Close Doors

                      Standard with soft close hinges

                      $929.00 $501.66
                      $1,080.00 $583.20
                      $742.00 $400.68
                      $49.00 $26.46
                      $60.00 $32.40
                      $71.00 $38.34
                      $1,101.00 $594.54
                      $307.00 $165.78
                      $372.00 $200.88
                      $433.00 $233.82
                      $447.00 $241.38
                      $480.00 $259.20
                      Load More Products
